vitrine refrigerante » vitrine réfrigérée » vitrine réfrigérée libre service » vitrine murale professionnelle
-
Description
| Basic parameters | |||
|---|---|---|---|
| Type | Refrigerated Multideck Cabinet | Model Model | 12AU |
| Design condition | 3（25℃，60%RH） | temperature range Temperature range | H1(1~10℃) |
| Energy Efficiency Grade | 3 | Refrigeration mode Refrigerating system | Air cooling Air-Cooling |
| （mm) Width | 1500/2000/2500/3750 ☑ custom | （L）Depth | 800/900/1000 ☑ custom |
| （mm) Height | 1900/2050 ☑ custom | （L）Effective Volume | - |
| Cabinet parameters | |||
| Cabinet /color | Black / White / grey ☑ custom | External Cabinet material | SGCC |
| Internal Cabinet material | SGCC | (mm) front end heigth | 360 |
| foaming | cyclopentane | Inside shelf | SGCC |
| Pallets | 5 | Pallet weight | 100KG/m² |
| Pallet Bearing | 150KG/m² | Side panel |
G: 23mm S： 36mm G: Glass Side Plate Thickness 23 mm S: Foamed Side Plate Thickness 36 mm |
| Silk Printing Color of Side Plate Glass | Silver gray | Glass | 19mm LOW-E hollow glass |
| Foot | Foundation bolt & Castor wheel | Night curtain | Deceleration curtain |
| (kg) Gross weight | 180KG/1000mm | ||
| Refrigerating system | |||
| Compressor | Emerson/Panasonic ☑ custom | temperature Evap Temp ℃ | -10℃ |
| Refrigerant | R404A | （g）Refrigerant charge | - |
| Evaporators | Copper Tube with aluminum fins | Condenser | Copper Tube with aluminum fins |
| Throttle modes | danfoss | temperature Temperature control | Electronic temperature controller |
| Defrost | Off-Cycle defrost | Defrost water treatment | Drain pipe |
| Electric parameter | |||
| Condenser Fan motor | Crew Depending on unit allocation | Evaporating fan | EBM |
| Lighting Canopy & Shelf | LED white X-union | power（W） Input Power | 288W |
| Plug | 16A | Plug | 220V/50HZ, 380V |
|
|
【12AU-A1 parameter】(The size can be customized)
| Name | Model | Installation dimensions(L×W×H)mm | volume(L) | show(m2) | Voltage/Frequency | temperature (℃) |
| 12AU-A1Fruit air curtain cabinet | 12AU-A1-2.0M | 2000×1000×2000 | 1500 | 5.00 | 220V/380V/50HZ | 2~10 |
| 12AU-A1Fruit air curtain cabinet | 12AU-A1-2.5M | 2500×1000×2000 | 1800 | 6.50 | 220V/380V/50HZ | 2~10 |
【12AU-A2 parameter】(The size can be customized)
| Name | Model | Installation dimensions(L×W×H)mm | volume(L) | show(m2) | Voltage/Frequency | temperature (℃) |
| 12AU-A2Fruit air curtain cabinet | 12AU-A2-2.0M | 2000×950×2000 | 1400 | 4.00 | 220V/380V/50HZ | 2~10 |
| 12AU-A2Fruit air curtain cabinet | 12AU-A2-2.5M | 2500×950×2000 | 1700 | 5.50 | 220V/380V/50HZ | 2~10 |
【12AU-A3 parameter】(The size can be customized)
| Name | Model | Installation dimensions(L×W×H)mm | volume(L) | show(m2) | Voltage/Frequency | temperature (℃) |
| 12AU-A3Fruit air curtain cabinet | 12AU-A3-2.0M | 2000×900×2000 | 1300 | 3.00 | 220V/380V/50HZ | 2~10 |
| 12AU-A3Fruit air curtain cabinet | 12AU-A3-2.5M | 2500×900×2000 | 1600 | 4.50 | 220V/380V/50HZ | 2~10 |
【12AU-A4 parameter】(The size can be customized)
| Name | Model | Installation dimensions(L×W×H)mm | volume(L) | show(m2) | Voltage/Frequency | temperature (℃) |
| 12AU-A4Fruit air curtain cabinet | 12AU-A4-2.0M | 2000×850×2000 | 1200 | 2.50 | 220V/380V/50HZ | 2~10 |
| 12AU-A4Fruit air curtain cabinet | 12AU-A4-2.5M | 2500×850×2000 | 1500 | 4.00 | 220V/380V/50HZ | 2~10 |
【12AU-A5 parameter】(The size can be customized)
| Name | Model | Installation dimensions(L×W×H)mm | volume(L) | show(m2) | Voltage/Frequency | temperature (℃) |
| 12AU-A5Fruit air curtain cabinet | 12AU-A5-2.0M | 2000×800×2000 | 1100 | 2.00 | 220V/380V/50HZ | 2~10 |
| 12AU-A5Fruit air curtain cabinet | 12AU-A5-2.5M | 2500×800×2000 | 1400 | 3.50 | 220V/380V/50HZ | 2~10 |
【12AU-A6parameter】(The size can be customized)
| Name | Model | Installation dimensions(L×W×H)mm | volume(L) | show(m2) | Voltage/Frequency | temperature (℃) |
| 12AU-A6Fruit air curtain cabinet | 12AU-A6-2.0M | 2000×750×2000 | 1000 | 1.50 | 220V/380V/50HZ | 2~10 |
| 12AU-A6Fruit air curtain cabinet | 12AU-A6-2.5M | 2500×750×2000 | 1300 | 2.50 | 220V/380V/50HZ | 2~10 |
